20mm Pitch Honeycomb Cooling Tower Fill in 750mm and 950mm Widths

This honeycomb cooling tower fill is manufactured in 750mm and 950mm widths, using a 20mm corrugation pitch and a 90° channel arrangement. When the corrugated sheets are assembled, they form a regular network of passages through the fill pack, providing space for circulating water and airflow within the cooling tower.

The 20mm channel spacing is a practical option for towers requiring a relatively open fill structure. Both widths are available with customized lengths and sheet thicknesses, allowing the finished packing dimensions to be matched to the tower's internal arrangement.

Product Specifications

• Width: 750mm, 950mm
• Length: Customized
• Thickness: Customized
• Corrugation Pitch: 20mm
• Channel Angle: 90°
• Material Options: PVC, CPVC, PP
• Assembly Method: Glue or hang

Honeycomb Channel Arrangement

The channel pattern is an important part of this fill design. With a 20mm pitch, the assembled sheets maintain defined passages rather than forming a tightly packed structure. The 90° corrugation arrangement also gives the fill a consistent internal geometry across the packing section.

For glued blocks, sheet alignment and bonding quality are important during assembly. Uneven joints or displaced sheets can change the channel openings, so maintaining the intended spacing throughout the block is part of the manufacturing process.

Block Assembly and Material Selection

The fill can be supplied as glued blocks or in a hanging configuration, depending on the tower's support system. The 750mm and 950mm widths provide two options for arranging the fill within the available packing space, while customized lengths and thicknesses allow further adjustment.

PVC is available for conventional operating conditions, while CPVC and PP provide additional material choices where operating temperature or water chemistry requires closer consideration. The final material should be selected according to the actual service conditions.

We manufacture this honeycomb fill with attention to sheet dimensions, channel alignment, and assembly requirements. For new installations or replacement projects, production dimensions can be adjusted to match the specified fill layout and installation method.
